(FSPEC04 CW) SPECIFICATION FORZA FIRST FD120(S) MINERAL CORE INTERNAL FLUSH DOORS

MANUFACTURER
Forza Doors Limited, 24a/24c Star Road Trading Estate, Star Road, Partridge Green, Horsham, West Sussex, RH13 8RA, England, UK
Telephone: +44(0)1403 711126, Fax: +44(0)1403 711229, Email: sales@forza-doors.com

DOOR REFERENCE & TYPE
A (single leaf) / B (double equal leaves) / C (double unequal leaves) / D (single leaf & overpanel) /  E (double equal leaves & overpanel) / F (double unequal leaves & overpanel). Overpanel (Transomed) in Composite frame only.

DOOR LEAF CORE
Rail & stile composite mineral core 51mm thick (average density 240kg/m3) faced with 2 layers 4mm MDF (minimum density 640Kg/m3) overall thickness 59mm
Weight 59mm; Nom 20kgs/m2

LIPPINGS
Concealed / exposed near match timber hardwood lipping (650kg/m3) to all four edges only before / after applying face finish.
Standard 3mm finished square

DOOR LEAF FACE FINISH
Wood veneer specie  ..........,    ref......., To match approved sample  ref......
Veneer cut: Crown cut / Quarter cut / Rift cut / Other
Veneer layon matching: Book match / Random match / Slip match / quarter match /other
Veneer grain direction: Vertical  / Horizontal / other
Sequential match of veneer feature of  adjacent doors, ref..... Floor plan drawing.
High Pressure Laminate (HPL)
Laminate to conform to EN 438 & ISO 4586, Laminate manufacturer, ref ......., colour
High impact PVC
Manufacturer, ref........., colour

FINISH AS DELIVERED
Wood veneer: Two coats high solid ultra violet (uv) cured lacquer, clear,  30% gloss, other.
Stained...........colour and finished with two coats high solid u/v clear lacquer, 30% gloss.
Limed wash and finished with one coat high solid u/v clear lacquer, 30% gloss.
Timber Lipping: Unfinished for finishing by others / Two coats of high-solid acid-catalyst lacquer.
For finishing by others:
Forza primed coat (FPC) for painting by others.

GLAZING
Steel Bead profile / Glass:   cloak/ 5mm Firelite
Size and position of aperture(s) :standard configuration V11, V12, V14, V16

DOOR FRAME
Composite mineral core /2mm lipping's and 2mm face veneers. Min dim 104mm X 47mm
Profile: applied stop. Min Dim 44mm x12mm see drawing ref. FZD0477

TIMBER FRAME FINISH AS DELIVERED
To compliment veneered door(s)
Two coats of high-solid acid-catalyst lacquer, clear/tinted, 20% gloss / other
Stained.......colour and finished with two coats high-solid acid-catalysed lacquer.
For finishing by others:
Primed one / two coats for paint finishing by others.

IRONMONGARY
Essential ironmongery specification of hinges, mortise latch/lock and door closer
Refer to Forza guidance on installation of FD120 hardware.

PERIMETER SEALS
Factory fitted to leaf(s) / frame, pvc cased intumescent/smoke/acoustic seals to manufacturers choice to meet fire & smoke control and sound insulation as specified in applicable test report or assessment. (Combined seals permitted).
Intumescent size: For composite frame head & stile 1no. 20 x 4 mm (7mm from pull face of frame reveal) & 1no. 25 x 4mm (33mm from pull face of frame reveal) bottom edge of leaf 1 no 47 x 1mm Forza flex seal (central) leaf meeting stile 1 No.20 x 4mm fitted in each leaf with one set 5mm from pull face and the other set 5mm from push face.

FIRE RESISTANCE RATING
FD120: 120 minutes to BS 476: Part 22: 1987
FD120S: 120 minutes to BS 476: Part 22: 1987 & cold smoke control to BS 476 Part 31.section 31.1.

SOUND INSULATION
Not Required/ Required

MECHANICAL PERFORMANCE
Modulas of rupture (ASTM c 133)psi. Min 900
Compressive Strength (ASTM c 109-93)psi Min 1586

MOISTURE CONTENT ON DELIVERY
Comply with BS EN 942: 2007 service climate 12-21°c. (door  <6)

SITE CONDITIONS
Conditions for storage, handling, stacking and covering during installation to comply with manufacturer's instructions.
Post installation temperature to be in region 12°c to 21°c and relative humidity range 40% to 60%.

INSTALLATION
Fix door(s) and composite frame in accordance with manufacturer's Installation guide and BS 8214: 2008 (Code of practice for fire door assemblies).
