Forza - Defining Doors
Veneer Guide

Single Door Specifications


Code Acoustic Summary
  dBRw Core FIRE leaf drw ref
SG44.32AS 32 44 N/F Flush FZD0715
SG44.34AGS 34 44 N/F V/P FZD0716
SG44.32A30S 32 44 30 Min Flush FZD0717
SG44.34A30GS 34 44 30 Min V/P FZD0718
SGFS44.40A30S 40 44 30 Min Flush FZD0783
SGFS44.38A30GS 38 44 30 Min V/P FZD0780
SG54.35AS 35 54 N/F Flush FZD0719
SG54.35AGS 35 54 N/F V/P FZD0720
SG54.35A60S 35 54 60 Min Flush FZD0721
SG54.35A60GS 35 54 60 Min V/P FZD0722
SGFK54.37AS 37 54 N/F Flush FZD0732
SGFK54.37AGS 37 54 N/F V/P FZD0733
SGFK54.37A60S 37 54 60 Min Flush FZD0734
SGFK54.37A60GS 37 54 60 Min V/P FZD0735
SGFS54.40AS 40 54 N/F Flush FZD0736
SGFS54.40AGS 40 54 N/F V/P FZD0737
SGFS54.40A60S 40 54 60 Min Flush FZD0738
SGFS54.40A60GS 40 54 60 Min V/P FZD0739
SGFS59.43AS 43 59 N/F Flush FZD0740
SGFS59.39AGS 39 59 N/F V/P FZD0741
SGFS59.43A60S 43 59 60 Min Flush FZD0742
SGFS59.39A60GS 39 59 60 Min V/P FZD0743
SGFS59.43A90S 43 59 90 Min Flush FZD0787
SGFS59.39A90GS 39 59 90 Min V/P FZD0784
SGFP64.38AGSS 38 64 N/F V/P FZD0796
SGFP64.39AGSS 39 64 N/F V/P FZD0797
SGFP64.40A60GSD 40 64 60 Min V/P FZD0803
SGFP64.40AGSD 40 64 N/F V/P FZD0804
SGFP64.41AGSD 41 64 N/F V/P FZD0805
SGFH64.36A120S 36 64 120 Min Flush FZD0798
ALUMINIMUM FRAME
ASG44.32A30S 32 44 30 Min Flush FZD0793
ASG44.34A30GS 34 44 30 Min V/P FZD0794
ASGFS44.35AS 35 44 N/F Flush FZD0795

fis1.jpg GAI_thumb-56px.jpgACS Logos1.jpgribalogo_thumb_56px.jpgForza Doors specification summaries are available through the RIBA Product Selector and NBs Plus
